System Requirements and Bill of Materials

In order to produce an estimated Bill of Materials it will be necessary to define key design criteria and details of the hazard. A hydraulic calculation will be required to produce a final Bill of Materials.

Trained and certified system designers should complete the design and review the Bill of Materials to ensure that the correct selections have been made.

Isometric Pipe Design

Before preparing to carry out the hydraulic flow calculations it will be necessary to configure the manifold set up and the pipe layout of the system using a 3D pipe designer. This will automatically provide input into the hydraulic flow calculations.

Hydraulic Flow Calculations

The final step is to complete the hydraulic flow calculations based on the system configuration and pipe layout.
